Ryo
Ryo’s name was inspired by the Amazon’s famous river. At night the shaft’s concave profile is filled with functional and gentle (yet efficient) light, while the round shape of the reflector allows for a very wide light spread. Ryo’s optics are designed to prevent light dispersion above the horizon (Dark Sky Compliant). The fixture comes in multiple heights and with both a directional and a bi-directional distribution, making this bollard suitable for both pathway lighting and to illuminate very large areas.
Fixture Body: Open pore Anodized and Powder Coated Die-Cast Aluminum.
Diffuser: UV Resistant Polycarbonate, Opaline.
Mounting: Open pore Anodized and Powder Coated Die-Cast Aluminum Base (Standard). Anchor Bolts available upon request.
Driver: Integral, 120-277V Dimmable 0-10V.
Wattages: 4.2W (9.8” Asymm.) – 10W (9.8” Round – 32.3” + 44.1” Asymm.) – 20W (32.3” + 44.1” Round).
Safety features: Fixture is equipped with Electrostatic discharge protection (4 KV), Surge Protection (0.5 KV) and Acquastop (anti-wicking).
IP rating: IP66 for protection against dust and water jets from any angle.
ETL Certification: ETL, wet location
Optics: General Illumination, with Asymmetric (Mono-Directional) or Round
(Bi-Directional) Emission
Color temperatures: 3000K – 4000K.
CRI: 80+
BUG Rating: B1-U0-G1 – Type I Asymmetrical (Dark Sky Compliant)
- Spec Page
-
- Photometry
-
